Precise Flow Rate Stability Ion Chromatography Instrument 220V 48 Positions

Precise Flow Rate Stability Ion Chromatography Instrument 220V 48 Positions

48 Positions Ion Chromatography Instrument

220V Ion Chromatography Instrument

Place of Origin:

Anhui, China

Brand Name:

Wayeal

Certification:

CE

Model Number:

IC6300

Contact Us
Request A Quote
Product Details
Product Name:
Ion Chromatography Instrument
Working Temperature:
10~40°C
Quantitative Repeatability:
≤0.004μS·cm-1/30min
Power Supply:
220V, 50~60Hz
Eluent Concentration Range:
KOH、MSA-0.1~100.0mM
Flow Rate Stability:
<0.2%
Injection Positions:
48 Positions
Column Capacity:
2pcs, 250mm And 150mm
Highlight:

48 Positions Ion Chromatography Instrument

,

220V Ion Chromatography Instrument

Payment & Shipping Terms
Minimum Order Quantity
1 Unit
Price
Negotiate
Packaging Details
Wooden Case
Delivery Time
35 days
Payment Terms
T/T
Supply Ability
30 Units/Month
Product Description

Description of Ion Chromatography Instrument:
As an efficient, sensitive, rapid and accurate analytical instrument, ion chromatograph plays an important role in modern analytical technology. First of all, ion chromatograph can separate and detect various ions. Secondly, ion chromatograph has fast analyzing speed, which usually takes only a few minutes to several minutes to complete the analysis of a sample. Finally, ion chromatograph has high sensitivity and selectivity, and can analyze a variety of ions at the same time, which provides a strong support for the analysis of complex samples.



Technical Parameters of Ion Chromatography Instrument:

Precise Flow Rate Stability Ion Chromatography Instrument 220V 48 Positions

Product Name Ion Chromatography Instrument
Working Conditions
Working Power 220V, 50Hz
System Parameters
Qualitative Repeatability ≤1%
Quantitative Repeatability ≤1%
Pump System
Flow Rate 0.001~15.000mL/min
Pressure Range 0~42MPa
Flow Rate Setting Error <0.2%
Flow Rate Stability <0.2%
Eluent
Flow Rate Range 0.001~3.000ml/min
Eluent Concentration Range KOH/MSA 0.1~100.0mM
Accuracy of Concentration 0.1mM
Max Working Pressure 21Mpa (3000psi)
Autosampler (AS2800 series)
Quantitative Repeatability Full loop injection <0.5%RSD
Linearity >0.9995
Injection Positions 48 Positions
Working Temperature 10~40°C
Sample Bottle 5mL/100mL
Injection Volume 10μL~400μL
Autosampler (AS3110 Series)
Injection Positions 120/64/92 positions for optional
Cooling Temperature 4~30°C
Injector Standard 500μL, options 250μL, 100μL, 2500μL
Column Oven
Temperature Range Room temperature, +5℃~70℃
Temperature Control Stability ≤0.1°C
Temperature Setting Error 0.05°C
Column Capacity 250mm and 150mm
Suppressor
Dead Volume 50μL
Suppression Capacity 170ueq/min
Pressure Resistance 3Mpa
Conductivity Detector
Baseline Noise ≤0.0005μS/cm
Baseline Drift ≤0.0005μS·cm-1/30min
Min Detection Concentration(Cl) ≤0.0005μg/mL
Min Detection Concentration (Li) ≤0.0002μg/mL
Cell Volume ≤0.4μL
Detector Resolution 0.00238nS/cm
Temperature Setting Error ±0.01°C
Ampere Detector
Drive Voltage Range -2.048V---2.048V
Drive Voltage Resolution 0.001V
Single Input Range Integral mode, 50pc---200uC
DC mode 1pA---74uA
Cell Volume <0.2μL
Min Detection Concentration I: 0.001μg/mL


Application Industries of Ion Chromatography Instrument:

  • Pharmaceutical Quality Control: Ion chromatography instrument can be used for the analysis of organic acids, inorganic salts and other components in drugs, as well as for stability and purity testing of pharmaceutical preparations.
  • Petrochemical Analysis: The ion chromatography instrument is commonly used in petrochemical analysis to determine the concentration of ions in crude oil, refined products, and additives. It can detect and quantify various anions and cations, such as chloride, sulfate, nitrate, and phosphate. It can also be used to monitor corrosion and scaling in pipelines and storage tanks.
  • Research and Development: The Ion Chromatography Instrument is a valuable tool for scientific research in chemistry, biology, and environmental science. It can be used to investigate the behavior of ions in solution, study the kinetics of chemical reactions, and develop new analytical methods. Its high sensitivity and accuracy make it a useful instrument for exploring complex chemical systems.
