Place of Origin:
Anhui, China
Brand Name:
Wayeal
Certification:
CE
Model Number:
IC6300
Description of Ion Chromatography Instrument:
The detector resolution of this Ion Chromatography Instrument is less than or equal to 1%, ensuring that you can easily distinguish between different analytes and obtain highly accurate quantification data. Injection volume ranges from 10uL to 4000uL, making it easy to use for both small and large sample sizes. And with 48 injection positions, you can analyze multiple samples simultaneously, saving time and increasing efficiency.
The flow rate setting rate is less than 0.2%, ensuring that you can maintain a consistent flow rate throughout your analysis, leading to more accurate and reliable results. Whether you are working in a research laboratory, quality control laboratory, or any other analytical laboratory, this Ion Chromatography Instrument is a must-have for all your analytical needs.
Technical Parameters of Ion Chromatography Instrument:
|
Precise and Reliable Advanced Ion Chromatography Instrument for Scientific Analysis |
|
|---|---|
| Product Name | Ion Chromatography Instrument |
| Working Conditions | |
| Working Power | 220V, 50Hz |
| System Parameters | |
| Qualitative Repeatability | ≤1% |
| Quantitative Repeatability | ≤1% |
| Pump System | |
| Flow Rate | 0.001～15.000mL/min |
| Pressure Range | 0~42MPa |
| Flow Rate Setting Error | ＜0.2% |
| Flow Rate Stability | ＜0.2% |
| Eluent | |
| Flow Rate Range | 0.001~3.000ml/min |
| Eluent Concentration Range | KOH/MSA 0.1~100.0mM |
| Accuracy of Concentration | 0.1mM |
| Max Working Pressure | 21Mpa (3000psi) |
| Autosampler (AS2800 series) | |
| Quantitative Repeatability | Full loop injection ＜0.5%RSD |
| Linearity | ＞0.9995 |
| Injection Positions | 48 Positions |
| Working Temperature | 10~40°C |
| Sample Bottle | 5mL/100mL |
| Injection Volume | 10μL~400μL |
| Autosampler (AS3110 Series) | |
| Injection Positions | 120/64/92 positions for optional |
| Cooling Temperature | 4~30°C |
| Injector | Standard 500μL, options 250μL, 100μL, 2500μL |
| Column Oven | |
| Temperature Range | Room temperature, ＋5℃~70℃ |
| Temperature Control Stability | ≤0.1°C |
| Temperature Setting Error | 0.05°C |
| Column Capacity | 250mm and 150mm |
| Suppressor | |
| Dead Volume | 50μL |
| Suppression Capacity | 170ueq/min |
| Pressure Resistance | 3Mpa |
| Conductivity Detector | |
| Baseline Noise | ≤0.0005μS/cm |
| Baseline Drift | ≤0.0005μS·cm-1/30min |
| Min Detection Concentration(Cl) | ≤0.0005μg/mL |
| Min Detection Concentration (Li) | ≤0.0002μg/mL |
| Cell Volume | ≤0.4μL |
| Detector Resolution | 0.00238nS/cm |
| Temperature Setting Error | ±0.01°C |
| Ampere Detector | |
| Drive Voltage Range | -2.048V---2.048V |
| Drive Voltage Resolution | 0.001V |
| Single Input Range | Integral mode, 50pc---200uC |
| DC mode | 1pA---74uA |
| Cell Volume | ＜0.2μL |
| Min Detection Concentration | I: 0.001μg/mL |
Support and Services of Ion Chromatography Instrument:
Our Ion Chromatography Instrument comes with comprehensive technical support and services to ensure optimal performance and reliability:
We also offer customized service plans to meet specific needs and budget requirements. Our team of experienced technicians is dedicated to providing prompt and effective solutions to any issues or concerns that may arise.
