Ultra Helium Mass Spectrometer Leak Detector Vaccum Helium Leak Detector

Place of Origin Anhui, China
Brand Name Wayeal
Certification CE
Model Number V6
Minimum Order Quantity 1 Unit
Price Negotiate
Packaging Details Wooden Case
Delivery Time 35 days
Payment Terms T/T, VISA
Supply Ability 200 Units/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Helium Leak Detector Differential Pressure Sensor Range 0Pa~ ±2000Pa
Sensor Error ±0.1%F.S. Power Supply AC 220V+10%, 50Hz
Weight 20KG Parameter Program Number 64 Groups (1~64)
High Light

Vaccum Helium Leak Detector

,

Ultra Helium Leak Detector

Leave a Message
Product Description

Introduction of Helium Leak Detector:



The "Helium Leak Detector" is an advanced industrial instrument designed for impeccable performance in detecting leaks with high precision and speed. This state-of-the-art vacuum leak detector leverages the unique properties of helium to identify even the most minuscule leaks in a variety of applications, making it an indispensable tool for ensuring the integrity and safety of vacuum systems.

One of the standout features of this Helium leak detector is its I/O input-output interface, which boasts 8 Inputs and 8 Outputs. This robust configuration permits seamless integration with various industrial systems, enabling automated control and monitoring of the leak detection process. By providing numerous connection options, users can achieve a high degree of flexibility in system design and functionality, tailoring the detector to meet specific operational needs.

The mini leak detection rate of the Helium Leak Detector operates at an impressive threshold in vacuum mode, down to 5*10-13 Pa.m3/s. This sensitivity level makes the detector ideal for applications where the detection of extremely small leaks is critical. The ability to identify leaks at such a low rate ensures that even the smallest imperfections that could compromise the integrity of a vacuum environment are swiftly detected and addressed.

When it comes to the leak rate display, this Helium leak detector offers a versatile and user-friendly interface. Users can view leak rates numerically, or through intuitive bar charts and graphs that provide a clear visual representation of the leak status. This multi-faceted approach to data presentation enhances the user experience by making the information accessible and easy to interpret at a glance, facilitating quick decision-making and response.

Moreover, the response time of the Helium Leak Detector is second to none, with a reaction time of less than 1 second (<1s). This rapid response time ensures that users are immediately alerted to the presence of helium, enabling quick action to isolate and rectify any leaks. The swift detection capability of this vacuum leak detector is crucial in maintaining operational efficiency and preventing potential downtime caused by leak-related issues.

The Helium Leak Detector is not only a tool for maintaining the vacuum integrity but also a safeguard for equipment and processes that rely on the absence of leaks. Its application spans across various industries including aerospace, automotive, semiconductor manufacturing, and more. Whether it's used for quality control, maintenance, or research and development, this helium leak detection system is engineered to deliver reliable and accurate results every time.

In summary, the Helium Leak Detector is a highly sophisticated vacuum leak detector that incorporates advanced technology to offer exceptional performance. With its comprehensive I/O interface, ultra-sensitive detection rate, dynamic leak rate display options, and unparalleled response time, this detector represents the pinnacle of helium leak detection systems. Its versatility and efficiency make it a valuable asset for any operation where the detection of vacuum leaks is of the utmost importance.



Technical Parameters of Helium Leak Detector:



Ultra Helium Mass Spectrometer Leak Detector Vaccum Helium Leak Detector Price
Differential Pressure Sensor Display Precision The value can be set to 0 to 4 decimal places
Sensor Range 0Pa~±2000Pa
Sensor Error ±0.1% F.S.
Direct Pressure Sensor Display Precision The value can be set to 0 to 4 decimal place
Recommended Test Pressure Range Standard V5 VH90B Mechanical Pressure Regulating -100kPa~ -1kPa
CH050 Mechanical Pressure Regulating 5kPa~ 100kPa
CH050D Mechanical Pressure Regulating 5kPa~ 89kPa
CH600 Mechanical Pressure Regulating 10kPa~ 600kPa
CH600D Mechanical Pressure Regulating 5kPa~ 490kPa
CH1000 Mechanical Pressure Regulating 50kPa~ 1200kPa
CH1000D Mechanical Pressure Regulating 50kPa~ 890kPa
CH4000 Mechanical Pressure Regulating 50kPa~ 4000kPa
CH500 Mechanical Pressure Regulating 10kPa~ 5000kPa (seals leak detector)
ZF500 Mechanical Pressure Regulating -100kPa~ -1kPa, 10kPa~ 500kPa
ZF2500 Mechanical Pressure Regulating -100kPa~ -1kPa, 50kPa~ 2400kPa
Standard V6 ZF600 Mechanical Pressure Regulating -100kPa~ -1kPa, 10kPa~ 600kPa (Optional)
ZF2400 Mechanical Pressure Regulating -100kPa~ -1kPa, 50kPa~ 2400kPa (Optional)
Sensor Error ±0.25% F.S.
Display Unit Test Pressure kPa,MPa,kg/cm2,psi,mbar,bar,Torr,mmH20,mmHg
  Leakage Rate Pa,kPa,Pas,Pa.m3/s,mL/s,mL/min,mL/h,L/min,L/h,SCCM
Parameter Program Number 64 Groups (1~64)
Test Beat Setting 0~99 seconds, test time 1800 second
Power Supply AA220V ±10%, 50Hz
Test Pressure Source Clean, dry, adequate flow, not less than 500KPa and 100KPa above the test pressure pressure source

Diamension





Standard V5 330mm*222mmm*448mm
Standard V6 321mm*205mm*460mm
Modular 160mm*268mm*273mm
Weight 20kg


Applications of Helium Leak Detector:



Wayeal Helium Leak Detector, hailing from Anhui, China, is a state-of-the-art device designed for a multitude of applications where precise leak detection is critical. This helium leak detector is suitable for a wide range of occasions and scenarios, from laboratory research to industrial applications such as aerospace, automotive, and pharmaceutical quality control, where maintaining a vacuum is essential for process integrity.







Support and Services of Helium Leak Detector:

The Helium Leak Detector product comes with comprehensive technical support and services designed to ensure that your equipment operates at peak performance. Our support includes access to a team of experts who can assist with any technical queries or troubleshooting needs. Furthermore, the product is backed by a range of services, including:



- On-site product training for operators to ensure proper usage and maintenance of the Helium Leak Detector.



- Regular software updates to keep the detector's functionality up-to-date with the latest improvements and features.



- Repair services, including the provision of replacement parts and detailed repair instructions, or the option to send the detector to our service center for professional repair.



Ultra Helium Mass Spectrometer Leak Detector Vaccum Helium Leak Detector 0



Methods of Helium Leak Detection (Helium Leak Detector)



Helium Vacuum Method

Ultra Helium Mass Spectrometer Leak Detector Vaccum Helium Leak Detector 1Helium Hood Method



Ultra Helium Mass Spectrometer Leak Detector Vaccum Helium Leak Detector 2



Negative Pressure Method

Ultra Helium Mass Spectrometer Leak Detector Vaccum Helium Leak Detector 3



Vacuum Chamber Helium Leak Detection and Recovery System (external filling)

Ultra Helium Mass Spectrometer Leak Detector Vaccum Helium Leak Detector 4





Vacuum Chamber Helium Leak Detection and Recovery System (internal filling)

Ultra Helium Mass Spectrometer Leak Detector Vaccum Helium Leak Detector 5





Sniffer Method

Ultra Helium Mass Spectrometer Leak Detector Vaccum Helium Leak Detector 6
