Sniffer And Vaccum Leak Detection Helium Leak Detector Machine Price

Place of Origin Anhui, China
Brand Name Wayeal
Certification CE
Model Number SFJ-16D
Minimum Order Quantity 1 Unit
Price Negotiate
Packaging Details Wooden Case
Delivery Time 35 days
Payment Terms T/T, VISA
Supply Ability 200 Units/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name SFJ-16D Helium Leak Detector Leak Detection Port DN25KF
Communication Interface RS232/485, LAN Detectable Quality 2, 3, 4 (H2, He3, He4)
Mini Leak Detection Rate(Pa.m3/s)/Vaccum Mode 5*10-13 Pa.m3/s Max Allowable Leak Detection Pressure (Pa) 1800Pa
Mini Leak Detection Rate(Pa.m3/s)/Sniffer Mode 2.5*10-9 Pa.m3/s Start Time (min) ≤1.58min
High Light

Sniffer Helium Leak Detector

,

Sniffer Vaccum Leak Detection Machine

,

Vaccum Helium Leak Detector

Leave a Message
Product Description

Introduction of Helium Leak Detector:



The helium leak detector is an indispensable tool for businesses and researchers who demand the highest level of leak detection sensitivity and accuracy. A helium leak detector is a type of instrument used to detect and locate leaks in a sealed system. The working principle of a helium leak detector is based on the fact that helium gas has a very small atomic size. When helium gas is sprayed around a sealed system, it can easily penetrate any leaks in the system and enter the detector.



Technical Parameters of Helium Leak Detector:



Sniffer and Vaccum Leak Detection Helium Leak Detector Machine Price

Product Name

Helium Leak Detector

Detection Method Helium Mass Spectrometer
Leak Detection Port DN25KF
Leak Rate Display Numbers, Bar Charts, Graphs
Response Time(s) <1s
User Interface 7inch Color Touch Screen
Operating temperature 0~40°C
Max Allowable Leak Detection Pressure (Pa) 1800
Communication Interface RS232/485, LAN
Detectable Quality 2, 3, 4 (H2, He-3, He-4)
Mini Leak Detection Rate(Pa.m3/s)/Sniffer Mode 5.0*10 -13 Pa.m3/s
Mini Leak Detection Rate(Pa.m3/s)/Vacuum Mode 2.5*10-9 Pa.m3/s
Startup Time (min) ≤1.58

Backing Pump

Scroll Vacuum Pump

Diamension 475*714*1168mm
Power Supply AC220V, 50Hz/60Hz
Language Chinese/English





Applications of Helium Leak Detector:



The Wayeal SFJ-16C helium leak detector is a sophisticated device designed to accurately identify and quantify leaks in various industrial applications.



Automotive industry: Helium leak detectors are used to test the fuel tanks, radiators, and other components of automobiles. They are used to detect leaks in the fuel system, cooling system, and air conditioning system.



Medical industry: Helium leak detectors are used to test the integrity of medical equipment such as anesthesia machines, oxygen concentrators, and ventilators. They are used to detect leaks in the system that could compromise patient safety.



Sniffer And Vaccum Leak Detection Helium Leak Detector Machine Price 0



Methods of Helium Leak Detection (Helium Leak Detector)



Helium Vacuum Method

Sniffer And Vaccum Leak Detection Helium Leak Detector Machine Price 1Helium Hood Method



Sniffer And Vaccum Leak Detection Helium Leak Detector Machine Price 2



Negative Pressure Method

Sniffer And Vaccum Leak Detection Helium Leak Detector Machine Price 3



Vacuum Chamber Helium Leak Detection and Recovery System (external filling)

Sniffer And Vaccum Leak Detection Helium Leak Detector Machine Price 4





Vacuum Chamber Helium Leak Detection and Recovery System (internal filling)

Sniffer And Vaccum Leak Detection Helium Leak Detector Machine Price 5





Sniffer Method

Sniffer And Vaccum Leak Detection Helium Leak Detector Machine Price 6



Sniffer And Vaccum Leak Detection Helium Leak Detector Machine Price 7
