Advanced GC-MS Gas Chromatography Mass Spectrometer with EI Ion Source

Basic Properties
Place of Origin: Anhui, China
Brand Name: Wayeal
Certification: CE
Model Number: GM6100
Trading Properties
Minimum Order Quantity: 1 Unit
Price: Negotiation
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30 Units/ Month
Tags

gas chromatography equipment

gc ms instrumentation

gc ms spectrometer GC gas chromatography
Specifications
Product name: GM6100 GC-MS Injection port: Split/Splitless
Control Precision: 0.001psi Control Range: 0–100 Psi
Optional Carrier Gases: N₂, H₂, He, Ar Maximum heating rate: ≥75°C/min
High Light:

gas chromatography mass spectrometer

,

gcms machine

,

chromatography mass spectrometer
Product Description

Technical Datas of GM6100 GC-MS

Working Conditions



Power Supply

220V ±10%, 50Hz ±2%

Ambiet Temperature

5°C to 40°C

Relative Humidity

20%~85%

GC Injection Port



Injection Port

Split/Splitless

Maximum Operating Temperature

450°C

Control Prexision

0.001psi

Control Range

0-100psi

Maximum Split Ratio

12500:1

Optional Carrier Gases

N2, H2, He, Ar

Flow Rate Range (with N2 as carrier gas)

0-500mL/min

Oven



Temperature Range

Above ambient temperature +4°C to 450°C

Programmable Temperature Ramps

32 steps/33 platforms

Maximum Heating Rate

≥75°C/min

Column Cooling Time (22°C ambient)

From 450°C to 50°C in less than 5 minutes

Maximun Program Run Time

9999.99 minutes

Environmental Temperature Sensitivity

Column temperature changes <0.01°C for every 1°C change in ambient temperaute

Mass Spectrometry Detector



Ion Source

OFN IDL lower than 10fg

Ionization Energy

15-250eV

Ion Source Temperature

150-350°C

Transfer Line Temperature

100-350°C

Mass Range

0.5amu-1250amu

Mass Stability

<0.10amu/48hrs

Acquistion Mode

Scan, SIM, Scan and SIM

Ion Detector

Triaxial detector equipped with high-energy dynode and a long-life, high-sensitivity electron multiplier

Maximum Scan Speed

20000amu/s

Dynamic Range

106

Fore Pump Pumping Speed

≥4m3/h

Turbo Molecular Pump Pumping Speed

≥250L/s

Autosampler



Sampler Capacity

16 positions

Solvent Bottle Positions

2

Waste Bottle Positions

1

Applications of GSMC in the Agricultural Industry

GC-MS, with its high sensitivity, high resolution, and powerful qualitative/quantitative capabilities, is widely used in the agricultural sector for critical applications such as pesticide residue testing, soil pollutant analysis, and agricultural product quality and safety monitoring.
1. Pesticide Residue Testing

  • Organophosphorus pesticides (chlorpyrifos, dichlorvos, methamidophos)
  • Organochlorine pesticides (DDT, endosulfan)
  • Pyrethroids (cypermethrin, deltamethrin)
  • Neonicotinoids (imidacloprid, thiamethoxam)

2. Soil and Irrigation Water Pollution Analysis

  • Organochlorine pesticide residue detection
  • Polycyclic aromatic hydrocarbons (PAHs)
  • Plasticizers (phthalates)

3. Agricultural Product Authenticity Verification

  • Honey adulteration detection (requires IRMS-coupled carbon isotope analysis)
  • Olive oil authenticity identification (fatty acid composition analysis)
  • Flavor and fragrance authenticity (e.g., vanillin source differentiation)

4. Veterinary Drug and Feed Safety Monitoring

  • Antibiotics (sulfonamides, tetracyclines)
  • Growth hormones (diethylstilbestrol, clenbuterol)
  • Feed additives (antioxidants BHT, BHA)

5. Plant Volatile Organic Compound (VOC) Analysis

  • Pest resistance research (e.g., insect-induced VOCs)
  • Floral aroma component analysis (e.g., rose, jasmine essential oils)
