Place of Origin:
Anhui, China
Brand Name:
Wayeal
Certification:
ISO90001, CE
Model Number:
Standard V5
CE Certificated Refrigeration Production Line Used Air Tightness Helium Leak Detector
Product Description
The Mass Spectrometer Leak Detector is a complete system for localization and measuring of leaks inside or outside of a product. This method uses so called tracer gas – helium, which is used to fill up the product connected to the detector. Helium leaks in/out of the tested product in to the detector where its partial pressure is measured and displayed on a screen.
Product Parameters
| CE Certificated Refrigeration Production Line Used Air Tightness Helium Leak Detector | ||||
| Main Models Parameters | ||||
| Differential Pressure Sensor | Display Precision | The value can be set to 0 to 4 decimal places | ||
| Sensor Range | 0Pa~ +2000Pa | |||
| Sensor Error | +0.1%F.S | |||
| Display Precision | The value can be set to 0 to 4 decimal places | |||
| Direct Pressure Sensor | Recommended Test Pressure Range | VH90B |
Mechanical Pressure Regulating |
-100kPa~ -1kPa |
| CH050 |
Mechanical Pressure Regulating |
5kPa~ 100kPa | ||
| CH600 | Electronic Pressure Regulation |
5kPa~ 89kPa | ||
| CH600D | Electronic Pressure Regulation |
5kPa~ 490kPa | ||
| CH1000 | Mechanical Pressure Regulating |
50kPa~ 1200kPa | ||
| CH1000D | Electronic Pressure Regulation |
50kPa~ 890kPa | ||
| CH4000 | Mechanical Pressure Regulating | 50kPa~4000kPa | ||
| CH500 | Mechanical Pressure Regulating |
10kPa~500kPa (seals leak detector) | ||
| ZF500 | Mechanical Pressure Regulating |
-100kPa~-1kPa,10kPa~500kPa | ||
| ZF2500 | Mechanical Pressure Regulating |
-100kPa~-1kPa,50kPa~2400kPa | ||
| ZF600 | Mechanical Pressure Regulating |
-100kPa～-1kPa,10kPa～600kPa(Optional) | ||
| ZF2400 | Mechanical Pressure Regulating |
-100kPa～-1kPa,50kPa～2400kPa(Optional) | ||
| Sensor Error | +0.1%F.S. | |||
| Display Unit | Test Pressure | kPa,MPa,kg/cm2,psi,mbar. bar,Torr. mmH,0,mmHg | ||
| Leakage Rate | Pa,kPa,Pa/s,Pa.m3/s,mL/s,mL/min,mL/h. L ./min. L /h. SCCM | |||
| Parameter Program Number | 64 groups (1~64) | |||
| Test Beat Setting | 0 ~ 999 seconds, test time 1800 seconds | |||
| Power Supply | AC 220V+10%,50Hz | |||
| Test Pressure Source | Clean, dry, adequate flow, not less than 500KPa and 100KPa above the test pressure source | |||
| Overall Dimensions | Standard V5 | 330mmx222mmx448mm | ||
| Standard V6 | 321mmx205mmx460mm | |||
| Modular | 160mmx268mmx273mm | |||
| Weight | About 20kgs | |||
Product Performance
1. Modular Integrated design
2. Automatic evacuation pressure and time setting, high leak detection efficiency;
3. It is suitable for direct pressure and flow rate leakage detection methods, and compatible with the use of single and multi-station requirements, to achieve one device to detect multiple products
4. Wireless remote-control function (optional);
Product Application
It is widely used in production line industries such as refrigeration and air conditioning, automotive parts, carbonated beverage containers food packages and aerosol packaging, as well as in the manufacture of steam products, gas bottles, fire extinguishers, tire valves, and numerous other products including all vacuum systems.
