Online CEMS Gas Analyzer Monitoring System For Nitrogen Oxide
| Product Name: | Continuous Emission Monitoring System For Nitrogen Oxide Of Flue Gas | Pretreatment: | Condensing Method |
| Nitrogen oxide measurement: | Converting Ovens | Measure Method: | UV Differential Method |
| Detection Item: | SO2, NOx, O2 | Product Package: | Wooden Case Or Customization |
| High Light: | Online cems gas analyzer,Nitrogen Oxide cems gas analyzer,cems monitoring system Analyzer |
||
CEMS Online Continuous Emission Monitoring System for Nitrogen Oxide of Flue Gas
Product Introduction
The CEMS1250 continuous emission monitoring system consists of four sub-systems: monitoring of gaseous pollutants (SO2, NO, O2, etc.), monitoring of flue gas parameters (temperature, pressure, flow rate, humidity, etc.) and data acquisition and data processing. It can continuously monitor SO2, NO, O2, soot concentration, flue gas temperature, pressure, flow rate, humidity and many other relevant parameters, and count the emission rate, total emission, etc.
Product Parameter
|
Product Name |
CEMS Online Continuous Emission Monitoring System for Nitrogen Oxide of Flue Gas |
|
Product Size |
930*730*2010mm |
|
Weight |
177KGS |
|
Measure Method |
UV Differential Method |
|
Nitrogen Oxide Measurement |
Heat Resistance Moisture Meter |
|
Contaminant Range |
SO2 concentration 0-45/100 mg/m3 NOX concentration 0-45/100 mg/m3 O2 content 0-25% |
|
Pre-processing |
Condensing Method |
|
Humidity meter measurements |
Heat Resistance Moisture Meter |
|
Oxygen content |
Electrochemical |
Product Performance
1. High reliability
1.1 The use of a xenon light source with a service life of 10 years.
1.2 Gas analyzer adopts grating spectroscopy and array sensing, no moving parts, high reliability
2. Easy maintenance, low maintenance cost
2.1 Simple system wiring, easy installation and maintenance.
2.2 The light source, gas chamber and spectrometer are connected by optical fibre, which makes the maintenance and replacement of each part simple and low cost.
3. High measurement accuracy
SO2, NO gas analysis using differential absorption spectroscopy (DOAS) technology, effectively solve the impact of water and other factors on the measurement accuracy.
Industry Application
Industrial pollutant gases
Thermal power plants
Industrial kilns, industrial boilers
Residential heating boilers.
