OEM Ammonia Nitrogen Analyzer Water Effluent Quality Monitoring System

Basic Properties
Place of Origin: Anhui, China
Brand Name: Wayeal
Certification: ISO, CE
Model Number: WS1503
Trading Properties
Minimum Order Quantity: 1
Price: Negotiation
Payment Terms: L/C,T/T,Western Union
Supply Ability: 10 Pieces per Month
Tags

water monitoring instruments

total nitrogen analyzer

Water Quality Sampler
Specifications
Product Name: Continuous Water Quality Monitoring Equipment Product Size: 380*470*600mm
Weight: 25KGS Measurement Error: ≤±5%
Error of Measurement: ≤±3% Zero Drift: ≤±0.02mg/L
High Light:

OEM ammonia nitrogen analyzer

,

Effluent ammonia nitrogen analyzer

,

OEM effluent quality monitoring system
Product Description

Ammonia Nitrogen Testing in Water Quality Continuous Water Quality Monitoring Equipment

Product Introduction

The salicylic acid spectrophotometry is adopted for WS1503 online automatic water quality monitor for ammonia nitrogen content. In the presence of alkaline medium and sodium nitrosoferricyanide, ammonium reacts with salicylate and hypochlorite ions to form a water-soluble blue compound, and the amount of ammonia nitrogen in the water sample is measured according to the Lambert-Bier law.

Product Parameter

Product Name Ammonia Nitrogen Testing in Water Quality Continuous Water Quality Monitoring Equipment
Measurement Method Salicylic Acid Spectrophotometric Method
Measurement Error ≤±3%
Zero Drift Zero-point Drift
Measurement Range 0~300.0mg/L
Repeatability ≤±2%
Range Drift ≤±1%

Product Performance

1. Unique three-stage precision photoelectric metering device for fast and accurate reagent withdrawal, significantly reducing the effects of peristaltic pump tube ageing.
2. Precise temperature compensation algorithms and ambient light elimination measures
3. Highly reliable reagent selection valves and anechoic flask assemblies with low failure rates and low maintenance effort.

Product Application

Sewage Treatment Plant, Enterprise Outfall.
