Outdoor Environmental Dust Ambient Air Quality Monitoring Instruments Monitor PM2.5 PM10 Particle
| Product Name: | PM2.5 Ambient Air Quality Monitoring Instruments | Measure Range: | 0-1000，0-10000 μg/m³ |
| Test Item: | Pm2.5 Pm10 | Analytical Method: | Beta Ray Attenuation Method |
| Zero Drift: | ±2%FS | Ambient temperature accuracy: | ±2℃ |
| High Light: | PM10 Ambient Air Quality Monitoring Instruments,PM2.5 Ambient Air Quality Monitoring Instruments,PM10 environmental dust monitor |
||
PM2.5 PM10 Particle Monitor Outdoor Dust Ambient Air Quality Monitoring Instruments
Product Introduction
The ambient particulate monitoring instruments is a particulate matter analyser based on the beta-ray method technology for the detection of PM10 and PM2.5 in the atmosphere. It is used for the detection and evaluation of particulate matter concentrations in ambient air quality parameters.
Product Performance
1. The equipment is designed with in-situ measurement and silent energy saving.
2. Simultaneous completion of sampling and measurement.
3. Dynamic heating to reduce the loss of volatile particulate matter.
4. Automatic elimination of interference from radioactive substances in the ambient air.
5. Accurate measurement, intuitive reading, low working noise, low energy consumption, wide range of applications.
Product Parameter
| Product Name | PM2.5 Ambient Air Quality Monitoring Instruments |
| Test Item | TSP,PM10,PM2.5 |
| Test principles | Beta Ray Attenuation Method |
| Range | (0-1000,0-10000) μg/m³ |
| Minimum Uisplay Unit | 0.1μg/m³ |
| Sampling Flow Rate | 16.67L/min |
| Detection Limit | 2μg/m³ |
| Zero Drift | ±2%FS |
| Measurement Period | 30-360min |
| Displays | LCD |
| Power | AC220V/50Hz |
| Ambient temperature accuracy | ±2℃ |
| Light source | C14(100uCi) |
Industry Application
Ambient air monitoring, leakage monitoring in industrial parks, regional background station monitoring, mobile environmental monitoring vehicles.
