GM6100 GCMS Featuring Autosampler or Six way Valve Supporting Advanced Gas Chromatography Mass Spectrometry Procedures in Control

GM6100 GCMS Featuring Autosampler or Six way Valve Supporting Advanced Gas Chromatography Mass Spectrometry Procedures in Control

GC 7890 GCMS with autosampler

GCMS six way valve support

gas chromatography mass spectrometry instrument

Place of Origin:

Anhui, China

Brand Name:

WAYEAL

Certification:

CE

Model Number:

GM6100

Contact Us

Request A Quote

GM6100 GCMS Featuring Autosampler or Six way Valve Supporting Advanced Gas Chromatography Mass Spectrometry Procedures in Control

Product Details

Instrument Type:

Gas Chromatography

Sampler:

Autosampler Or Six-way Valve

Weight:

35 Kg

Position:

16

Model:

GC-7890

Carrier Gas:

Helium

Maximum Heating Rate:

≥75°C/min

Interface:

USB And Ethernet

Highlight:

GC 7890 GCMS with autosampler

,

GCMS six way valve support

,

gas chromatography mass spectrometry instrument

Payment & Shipping Terms

Minimum Order Quantity

1

Price

Negotiate

Packaging Details

Wooden Case

Delivery Time

35 working days

Payment Terms

T/T, LC

Supply Ability

20 units/Month

RELATED PRODUCTS

Good price Qualitative Repeatability ≤0.1 Percent Gas Chromatography Instrument Featuring Autosampler or Six-way Valve and Power Supply 50 60Hz for Results online

Qualitative Repeatability ≤0.1 Percent Gas Chromatography Instrument Featuring Autosampler or Six-way Valve and Power Supply 50 60Hz for Results

Get Best Price

Good price GM6100 GCMS Featuring Autosampler or Six way Valve Supporting Advanced Gas Chromatography Mass Spectrometry Procedures in Control online

GM6100 GCMS Featuring Autosampler or Six way Valve Supporting Advanced Gas Chromatography Mass Spectrometry Procedures in Control

Get Best Price

Good price Control Range 0 to 100 Psi Gas Chromatography Instrument Including USB and Ethernet Interface and 16 Position for Sample Testing online

Control Range 0 to 100 Psi Gas Chromatography Instrument Including USB and Ethernet Interface and 16 Position for Sample Testing

Get Best Price

Good price USB And Ethernet Interface Equipped GCMSMS Device 220V±10% Optimized for High Throughput Analysis and Data Acquisition online

USB And Ethernet Interface Equipped GCMSMS Device 220V±10% Optimized for High Throughput Analysis and Data Acquisition

Get Best Price

Contact Us

export@wayeal.com.cn

Contact Now

Product Description

System Introduction of GM6100 Gas Chromatograph Mass Spectrometer

The Wayeal GM6100 Series integrates the upgraded GC6100 gas chromatograph with the high-performance MSD7000 mass spectrometry detector, creating a precise and intelligent GC-MS system. Advanced controls and intelligent algorithms ensure continuous, stable operation. Through a single intuitive software interface, users can automate the entire process—from sample injection to data analysis—reducing human error and increasing efficiency. The system offers a more efficient, precise, and intelligent analytical experience.

Techncial Parameters of GM6100 GCMS

Working Conditions
Power Supply	220V ±10%, 50Hz ±2%
Ambiet Temperature	5°C to 40°C
Relative Humidity	20%~85%
GC Injection Port
Injection Port	Split/Splitless
Maximum Operating Temperature	450°C
Control Prexision	0.001psi
Control Range	0-100psi
Maximum Split Ratio	12500:1
Optional Carrier Gases	N2, H2, He, Ar
Flow Rate Range (with N2 as carrier gas)	0-500mL/min
Oven
Temperature Range	Above ambient temperature +4°C to 450°C
Programmable Temperature Ramps	32 steps/33 platforms
Maximum Heating Rate	≥75°C/min
Column Cooling Time (22°C ambient)	From 450°C to 50°C in less than 5 minutes
Maximun Program Run Time	9999.99 minutes
Environmental Temperature Sensitivity	Column temperature changes <0.01°C for every 1°C change in ambient temperaute
Mass Spectrometry Detector
Ion Source	OFN IDL lower than 10fg
Ionization Energy	15-250eV
Ion Source Temperature	150-350°C
Transfer Line Temperature	100-350°C
Mass Range	0.5amu-1250amu
Mass Stability	<0.10amu/48hrs
Acquistion Mode	Scan, SIM, Scan and SIM
Ion Detector	Triaxial detector equipped with high-energy dynode and a long-life, high-sensitivity electron multiplier
Maximum Scan Speed	20000amu/s
Dynamic Range	10⁶
Fore Pump Pumping Speed	≥4m³/h
Turbo Molecular Pump Pumping Speed	≥250L/s
Autosampler
Sampler Capacity	16 positions
Solvent Bottle Positions	2
Waste Bottle Positions	1
