Single Beam 185 - 910nm AAS Atomic Absorption Spectroscopy For Mining Metal

Place of Origin Anhui, China
Brand Name Wayeal
Certification ISO, CE
Model Number AA2230
Minimum Order Quantity 1
Price Negotiation
Packaging Details One piece per wooden case
Delivery Time 25 days
Supply Ability 20 Pieces Per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name AAS Spectrometer Resolution(%) ≤20
Zero Drift(Abs/30min) ±0.0015 Apparent Atomization Rate(%) ≥10
Repeatability(Flame RSD%) ≤0.15 Linearity Error(%) ≤5
High Light

Single Beam AAS Spectrophotometer

,

910nm AAS Atomic Absorption Spectroscopy

,

185nm AAS Atomic Absorption Spectroscopy

Leave a Message
Product Description

Single Beam 185-910nm AAS Atomic Absorption Spectroscopy for Mining Metal Analysis

Product Introduction



Atomic absorption spectrometry (AAS) is an easy, high-throughput, and inexpensive technology used primarily to analyze elements in solution. As such, AAS is used in food and beverage, water, clinical research, and pharmaceutical analysis. It is also used in mining operations to determine, for instance, the percentage of precious metal in ores.


Product Parameter



Single Beam 185-910nm AAS Atomic Absorption Spectroscopy for Mining Metal Analysis
Wavelength range(nm) 185-910
Wavelength indication error(mm) ±0.2
Wavelength repeatability(nm) ≤0.05
Broadband deviation(nm) ±0.015
Resolution(%) ≤20
Instantaneous noise(Abs) ±0.002
Zero drift(Abs/30min) ±0.0015
Boundary energy:instantaneous noise(Abs) ≤0.015
Detection limit(Flame:Cu ug/mL)) ≤0.002
Apparent atomization rate(%) ≥10
Detection limit(Graphite Furnance: Cd pg) ≤0.3
Repeatability(Flame RSD%) ≤0.15
Repeatability(Graphite Furnance RSD%) ≤1
Linearity error(%) ≤5
Background correction capability ≥70


Product Features


1. Stability: Double-beam system can automatically compensate the light source drift and wavelength drift caused by the variation of temperature (with the function of the eliminating the affection of wavelength drift on the base line stability) and electronic circuit drift so as to reach a good basic line stability.


2. Full-reflection dual-beam optical path, high optical path stability


3. High precision of measurement: Gas path system is equipped with precision pressure stabilizing and current stabilizing devices to reach stable flame and low noise. Specially designed fine light beam passes through the flame to ensure a high precision analytical test and low characteristic concentration.


4. 6 lamp holders preheat simultaneously to improve detection efficiency




Product Application


Food, medicine, environment, metallurgy, agriculture and disease control
