150MPa UHPLC Ultra High Performance Liquid Chromatography With Binary Pump

Place of Origin Anhui, China
Brand Name Wayeal
Certification ISO, CE
Model Number LC3600
Minimum Order Quantity 1
Price Negotiation
Packaging Details One piece per wooden case
Delivery Time 20 days
Payment Terms L/C, T/T
Supply Ability 30 Pieces Per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name UHPLC Chromatography Instruments Number Of Arrays 1024
Warranty 1 Year Power Supply 220V 50HZ
Ambient Temperature 10-40℃ Light Source Deuterium (D2) Lamp
High Light

150MPa UHPLC Machine

,

150MPa Ultra High Performance Liquid Chromatography

,

UHPLC Machine With Binary Pump

Leave a Message
Product Description

150MPa UHPLC Ultra High Performance Liquid Chromatography with Binary Pump

Product Description


The ultra high performance liquid chromatography instrument will complete the work of previous multiple HPLCs in less time, with higher separation, less reagent consumption, more intelligence and convenience, and greatly reduce the management cost of the instrument. It can complete the work of multiple high-performance liquid chromatographs in a shorter time with higher resolution, less reagent consumption, more intelligent and convenient and greatly reducing the management cost of the instrument.



Product Parameter



150MPa UHPLC Ultra High Performance Liquid Chromatography with Binary Pump
Work Power

220V, 50HZ

Ambient Temperature10-~40°C
Relative Humidity20-85%
System Indicators
Qualitative Repeatiblity RSD ≤0.1%
Quantitative RepeatabilityRSD ≤0.3%
High Pressure Constant Current Pump
Pump Drive ModeLinear Motor Pump
Gradient ModeBinary (4-way solvent)
Flow Setting Range0.0001~2ml/min
Flow Setting Increment0.001ml/min
Max Operating Pressure150MPa
Flow Setting Error±1.1%
Flow Stability≤0.09% RSD
Gradient Stability ≤0.02% RSD
Column Oven
Temperature Setting Range20~90°C
Temperature Stability ± 0.3°C/h
Error of Temperature Setting Value± 0.5°C
Autosampler
Maximum Withstand Pressure150MPa
Injection Volumn Range0.1~10ul
Injection Volume Error± 0.2ul (Injection Volume 10ul)
Injection Repeatability < 0.3% RSD
LinearityR≥0.999
Cross-contamination< 0.001%
Number of Smples96 Vials  (2*48, 2ml)
Temperature Seting Range4~40 °C
Temperature Stability± 1°C
Sampling Speed15s
Ultra-efficient DAD Detector
Baseline Noise≤10-6 AU
Baseline Drift≤0.9x10-3 AU/h
Minimum Test Concentration

2×10-9g/ml (naphthalene/methanol)

Wavelength Range190~800nm
Wavelength Indication Error≤ ±1nm
Wavelength Repeatability≤ ± 0.1nm
Linear2.0 AU
Sampling RateUp to 100Hz
Number of Arrays1024
Light SourceDeuterium (D2) Lamp


Product Performance

1. High-precision ultra-high-pressure infusion unit

2. Low system diffusion volume and optimized flow path

3. Needle-in-flow autosampler with ultra-low injection cycle time

4. Extremely low cross-contamination

5. Active preheat function, fast warming rate



Product Application


Food, medicine, environment, agriculture and scientific research
