Place of Origin:
Anhui, China
Brand Name:
Wayeal
Certification:
ISO, CE
Model Number:
LC3600
LC3600 Analysis Instrument Hplc Ultra High Performance Liquid Chromatography Instrument
Product Description of High Performance Liquid Chromatography Instrument
The revolution of Pioneer Ultra Performance Liquid Chromatography lies in the high-precision ultra-high pressure infusion unit, low system diffusion volume and optimized flow path, the ultra-low injection cycle of the needle in the flow path autosampler, and extremely low cross-contamination. It can give full play to the ultimate performance of sub-two-micron chromatographic columns, bring higher speed, sensitivity and resolution, and bring higher efficiency to customers
It can complete the work of multiple high-performance liquid chromatographs in a shorter time with higher resolution, less reagent consumption, more intelligent and convenient and greatly reducing the management cost of the instrument.
Parameters of High Performance Liquid Chromatogaphy Instrument
| Working Condition | |
| Working Power | 220V, 50Hz |
| Ambient temperature | 10-40℃ |
| Relative humidity | 20-85% |
| System Indicators | |
| Qualitative Accuracy | RSD≤0.1% |
| Quantitative Repeatability | RSD≤0.3% |
| High pressure constant current pump | |
| Pump drive mode | Linear motor pump |
| Gradient mode | Binary (4-way solvent) |
| Flow Setting Range | 0001-2.0000mL/min |
| Flow setting increment | 0.001mL/min |
| Maximum operating pressure | 150MPa |
| Flow setting value error | ±1.1% |
| Flow stability | ≤0.09% RSD |
| Gradient stability | ≤0.2% RSD |
Product Performance of High Performance Liquid Chromatography Instrument
Infusion Pump
The super high-efficiency binary high-pressure pump is the core component of the super high-efficiency liquid phase. It uses ultra-high pressure linear motor pumps with a maximum pressure of 150MPa and a flow range of 0-2mL/min, covering the best use range of sub-two-micron chromatographic columns. The dynamic compression compensation of the ultra-efficient binary high-pressure pump adopts high-precision real-time pressure following technology to achieve the effect of "zero fluctuation" and brings extremely high flow stability. As a high-end liquid phase pump, the ultra-efficient binary high-pressure pump comes standard with four-way solvent switching, electric vent valve, six-way online degassing, and support for leak detection and other rich functions, enabling users to get rid of manual operation.
Autosampler
The ultra-efficient autosampler adopts ultra-high-pressure needle in the flow path non-destructive sampling technology, with a very low sampling cycle period. Since the injection needle is always flushed in the high-pressure flow path, it has extremely low cross-contamination. The refrigerated sample chamber can store biological samples and other easily deteriorating test materials.
Column Oven
The ultra-efficient column thermostat has an active preheating function, the heating rate is extremely fast, and the mobile phase can be fully preheated in the ultra-efficient and extremely short detection time, bringing excellent detection results.
Product Application
Food, medicine, environment, agriculture and scientific research
