220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL

220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL

190 Nm Liquid Chromatography System

Liquid Chromatography System With Injection

800 Nm Liquid Chromatography System

Place of Origin:

China

Brand Name:

Wayeal

Certification:

CE

Model Number:

LC3200

Contact Us
Request A Quote
220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL
220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL 220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL 220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL 220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL
Product Details
Product Name:
High Performance Liquid Chromatography Instrument
Number Of Samples:
120 Positions
Linearity:
>0.9999
Interface:
USB/Ethernet
Power Supply:
220V, 50Hz
Flow Rate:
0.001-10mL/min
Wavelength Range:
190-800nm
Column Temperature:
4-85°C
Highlight:

190 Nm Liquid Chromatography System

,

Liquid Chromatography System With Injection

,

800 Nm Liquid Chromatography System

Payment & Shipping Terms
Minimum Order Quantity
1 Unit
Price
Negotitate
Packaging Details
Wooden Case
Delivery Time
30 Days
Payment Terms
T/T
Supply Ability
50 Units/Month
RELATED PRODUCTS
Good price LC3400 75MPa Ultra Fast HPLC System High Performance Liquid Chromatography Machine With 108 Injection Bits online

LC3400 75MPa Ultra Fast HPLC System High Performance Liquid Chromatography Machine With 108 Injection Bits

Get Best Price
Good price LC3400 75MPa Chromatography Machine Hplc Liquid Chromatography Instrument System online

LC3400 75MPa Chromatography Machine Hplc Liquid Chromatography Instrument System

Get Best Price
Good price LC3400 Flow To Needle High Performance Liquid Hplc Chromatography Instrument 220V online

LC3400 Flow To Needle High Performance Liquid Hplc Chromatography Instrument 220V

Get Best Price
Good price LC3400 62MPa Hplc High Performance Liquid Chromatography Instrument online

LC3400 62MPa Hplc High Performance Liquid Chromatography Instrument

Get Best Price
Contact Us
+8613586823203
export@wayeal.com.cn
Contact Now
Product Description

High Performance Liquid Chromatography(HPLC) System with Injection Volume 1-100 μL and 220V/50Hz



Description of High Performance Liquid Chromatogaphy Instrument:

Wayeal’s High Performance Liquid Chromatograph Instrument (HPLC) is a sophisticated chromatography instrument designed for high-precision chromatography applications. The HPLC instrument is specifically designed to ensure high performance, accuracy, and reproducibility. Its advanced hardware and software capabilities make it ideal for a wide variety of chromatography applications.



Technical Data of High Performance Liquid Chromatography Instrument

Manufacturer: Wayeal
Product Name: Liquid Chromatography Instrument
Working Power Supply 220V, 50Hz
Ambient Temperature 10~40°C
Relative Humidity 20~85%
Qualitative Repeatability ≤0.2%
Quantitative Repeatability ≤0.4%
High Pressure Constant Flow Pump
Flow Rate Range 0.001~10.000mL/min
Setting Step 0.001mL/min
Pressure Range 0~42MPa
Pressure Pulsation 0.1MPa
Flow Rate Set Error ±0.2%
Flow Rate Stability RSD≤0.06%
Gradient Error ±1%
Column Oven
Temperature Control Range 4~85°C
Temperature Stability ±0.02°C
Temperature Setting Resolution 0.1°C
Autosampler
Injection Volume Repeatability ＜0.5%RSD
Linearity ＞0.9999
Cross Contamination ＜0.002%
Injection Volume Accuracy Error ±1%
Sample Positions 120
Injection Volume 1~100μL
UV Detector
Baseline Noise ≤2.0*10-6Au
Baseline Drift ≤1*10-5Au/h
Mini Detection Concentration ≤3.0*10-9g/mL (naphthalene/methanol)
Spectral Range 188~900nm
Wavelength Error ≤±0.1nm
Wavelength Repeatability ≤±0.1nm
Linearity Range ≥103
DA Detector
Baseline Noise ≤4*10-5Au
Baseline Drift ≤3*10-5Au/h
Mini Detection Concentration ≤2*10-8g/mL
Spectral Range 190~800nm
Wavelength Error ≤±0.1nm
Wavelength Repeatability ≤±0.1nm
Linearity Range ≥ 104
ELS Detector
Baseline Noise ≤ 0.0037mV
Baseline Drift ≤ 0.0026mV/30min
Evaporation Gas Flow Range (0 ~ 3) SLM
Atomization Temperature Range Room temperature ~ 90℃
Evaporation Temperature Range Room temperature～110℃
Detection Chamber Temperature Range Room temperature～60℃
Input Air Pressure (4 ~ 7) bar
FL Detector
Baseline Noise ≤ 5×10-6 FU
Baseline Drift ≤ 2 × 10-5 FU/30min
Spectral Range (200 ~ 650) nm
Wavelength Error ± 0.1 nm
Linearity Range ≥ 104
RI Detector
Detection Range 0.25 ~ 512 μRIU
Linearity Range ≥ 600 μRIU
Response Time 0.1, 0.25, 0.5, 1, 1.5, 2, 3, 6 sec;
Cell Volume 8μL



Applications of High Performance Liquid Chromatography Instrument:

The Wayeal high performance liquid chromatography LC3200 is suitable for a variety of applications, including environmental analysis, pharmaceutical analysis, food safety analysis, forensic analysis, and biochemical research. It is an ideal choice for laboratories and research centers that demand high performance and accuracy. The instrument is capable of producing precise and accurate results with low levels of detection and quantification. Its advanced functionality and user-friendly interface make it easy to use and maintain.

220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL 0

220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL 1220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL 2220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL 3220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL 4220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL 5220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL 6220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL 7220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL 8
