Advanced LC-MS Liquid Chromatography Mass Spectrometer with Electrospray Ionization

Name: Advanced LC-MS Liquid Chromatography Mass Spectrometer with Electrospray Ionization
Brand: Anhui Wanyi Science and Technology Co., Ltd.
SKU: TQ9200
Price: 15,400.00 USD
Availability: InStock

Basic Properties

Place of Origin: Anhui, China

Brand Name: Wayeal

Certification: CE

Model Number: TQ9200

Trading Properties

Minimum Order Quantity: 1 Unit

Price: Negotiation

Payment Terms: L/C, T/T

Supply Ability: 30 Units/ Month

hplc liquid chromatography

hplc testing equipment

hplc lab equipment

Specifications

Product name:	Liquid Chromatography Mass Spectyrometer	Ionization method:	ESI
Mass accuracy:	0.1 Da	Massstability:	0.1 Da/24h
Limit of detection (rifampicin):	0.1 Pg	Sensitivity:	S:N >20w:1 On A 1 Pg Risperdal Column
High Light:	liquid chromatography mass spectrometer , UPLC-MS , chromatography mass spectrometer

Product Description

Technical Parameters of TQ9200

Working conditions
Working power supply	220V±22V, 50Hz±0.5Hz
Ambient temperature	15-30°C
Relative humidity	not more than 80%
UHPLC
Pump drive mode	linear motor pump
Gradient mode	binary (4-waysolvent)
Flow rate setting range	0.001-2.000mL/min
Flow rate setting increment	0.001mL/min
Maximumoperating pressure	150MPa
Degassing	5-channel online degassing
Autosampler
Maximumwithstand pressure	150MPa
Sampling volume range	0.1-20.0μL (50μL optional)
Linearity	R≥0.9999
Cross-contamination	<0.004 %
Number of samples	108 (2*54,2 ml), supports 96 shallow well plate, 96 deep well plate, 384 well plate
Temperature setting range	4.0~40.0 ℃ (optional refrigeration)
Temperature stability	±2 ℃
Feed rate	12s
Column temperaturechamber
Temperature setting range	20.0-90.0 ℃
Temperature stability	±0.02 ℃/h
Temperature setting value error	± 0.1 ℃
Triple quadrupole mass spectrometer
Mass analysis range	5-1250
Scanning speed	12000 Da/s
Mass resolution	0.6-0.8 Da (609 mass peaks)
Linearity range	≥1E4
Mass accuracy	0.1 Da
Massstability	0.1 Da/24h
Limit of detection (rifampicin)	0.1pg
Sensitivity	S:N >20w:1 on a 1pg Risperdal column
System indicators
Qualitative reproducibility	RSD≤5%
Quantitative reproducibility	RSD≤5%

Applications of Liquid Chromatography Mass Spectrometer

Chemical & Materials Industry
1. Fine Chemicals
Purity and impurity analysis of surfactants, dye intermediates.
2. Polymer Additives
Antioxidants, UV stabilizers (e.g., BHT, Irganox series).
