AA2230 Flame Atomic Absorption Photometer AAS In Agriculture Analysis

Place of Origin Anhui, China
Brand Name Wayeal
Certification ISO, CE
Model Number AA2230
Minimum Order Quantity 1
Price Negotiation
Packaging Details One piece per wooden case
Delivery Time 25 days
Supply Ability 20 Pieces Per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Flame Atomic Absorption Spectroscopy Models AA2230
Apparent Atomization Rate(%) ≥8 Detection Limit(Graphite Furnance Cd Pg) ≤0.3
Repeatability(Flame RSD%) ≤0.2 Linearity Error(%) ≤10
High Light

Flame Atomic Absorption Photometer

,

Flame Atomic Absorption Spectroscopy

,

AAS Atomic Absorption Spectroscopy Machine

Leave a Message
Product Description

AA2230 Flame Atomic Absorption Photometer AAS Atomic Absorption Spectroscopy Machine in Agriculture Analysis

Product Introduction

Atomic Absorption Spectrophotometry (AAS) is used to determine the concentrations of individual elements in a sample by measuring the selective absorption of light by gaseous atoms produced by spraying a solution into a flame (FAAS) or by evaporation in a carbon tube (CFAAS). AAS is commonly used for trace metal analysis of a wide range of sample types in the environmental sciences, food and beverage, chemical and pharmaceutical sectors for impurity or contamination monitoring and quality control, as well as the rapid assessment of raw materials. It is also used in a clinical setting for the analysis of biological fluids, such as blood and urine.


Product Parameter



AA2230 Flame Atomic Absorption Photometer AAS Atomic Absorption Spectroscopy Machine in Agriculture Analysis

Models

AA2230

Wavelength Range(nm) 185-910
Wavelength Indication Error(mm) ±0.2
Wavelength Repeatability(nm) ≤0.05
Broadband Deviation(nm) ±0.015
Resolution(%) ≤20
Instantaneous Noise(Abs) ±0.002
Zero Drift(Abs/30min) ±0.0015
Boundary Energy:Instantaneous Noise(Abs) ≤0.015
Detection Limit(Flame:Cu ug/mL)) ≤0.002
Apparent Atomization Rate(%) ≥10
Detection Limit(Graphite Furnance: Cd pg) ≤0.3
Repeatability(Flame RSD%) ≤0.15
Repeatability(Graphite Furnance RSD%) ≤1
Linearity Error(%) ≤5
Background Correction Capability ≥70






Product Features


1. Stability: Double-beam system can automatically compensate the light source drift and wavelength drift caused by the variation of temperature (with the function of the eliminating the affection of wavelength drift on the base line stability) and electronic circuit drift so as to reach a good basic line stability.


2. Full-reflection dual-beam optical path, high optical path stability


3. High precision of measurement: Gas path system is equipped with precision pressure stabilizing and current stabilizing devices to reach stable flame and low noise. Specially designed fine light beam passes through the flame to ensure a high precision analytical test and low characteristic concentration.


4. 6 lamp holders preheat simultaneously to improve detection efficiency



Product Application



Metal analysis of mining and geology, mining and geology, mining and geology, pharmaceuticals, foods and beverages, oil and petroleum, agriculture, forensics.
