Full Automatic Vacuum Leak Detection System Helium Leak Test Chamber For Cell Shell
| Place of Origin | Anhui, China |
|---|---|
| Brand Name | Wayeal |
| Certification | ISO, CE |
| Minimum Order Quantity | 1 |
| Price | Negotiation |
| Packaging Details | One piece per wooden case |
| Delivery Time | 30 days |
| Payment Terms | L/C, T/T |
| Supply Ability | 10 Pieces Per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Helium Leak Detecion Equipment Vacuum Leakage Detection System Of Cell Shell | Min Detectable Leakage Rate | 5*10-3 Pa.m3/s |
|---|---|---|---|
| Response Time | <1s | Evacuation Pressure | ≤2000Pa |
| Missed Kill Rate | 0 | Equipment Failure Rate | ≤1% |
| High Light | Vacuum Leak Detection System chamber,Helium Vacuum Leak Detection System,helium leak test chamber |
||
Product Description
Helium Leak Detecion Equipment Vacuum Leakage Detection System of Cell Shell
Product Introduction
The vacuum acuum leak detection systems is suitable for leakage detection of lithium battery cover plate and cell shell. It has high degree of automation, and can realize full-automatic unmanned production.
Product Parameter
| Automatic Vacuum Chamber Helium Leak Detection System for Lithium Battery | ||
| Workpiece | Metal bipolar plates, Membrane electrode | |
| Product Size | 4500*2000*2000mm/Customized | |
| Power | 20KW | |
| Weight | 3000KG/Depends on real item | |
| Leak detector opening detecting pressure | ≤30pa | |
| Workpiece Evacuation pressure | ≤2000pa | |
| Helium leak detector parameters | Display ranges | 1.0*10-3~10-13 Pa.m3/s |
| Minimum detectable leakage rate | 5*10-13 Pa.m/s | |
| Response Time | <1S | |
| Leak rate control setting | Set up on the system according to your process requirements | |
| Overkill Rate | ≤1% | |
| Leakage rate | 0 | |
| Equipment failure rate | ≤1% | |
| Yield rate | ≥99.9% | |
| Leak detection tempo | ≥3PPM | |
| Motro Power | 600 W | |
| Ultimate pressure | 1000 Pa | |
Product Performance
1. It has high leak detection accuracy and low false detection rate, which ensures the quality of lithium battery after passing the inspection;
2. The helium can be recycled, with a recovery rate as high as 85%;
3. The system has automatic helium cleaning function, which can quickly and efficiently clean the helium pollution caused by leaking workpieces;
4. Workpiece pick-and-place robot or manipulator can be selected to realize full-automatic detection and 24-hour full-automatic unmanned production;
Product Application
Power switchgear, ring main unit, pole top switch, power castings
