Helium Leak Detector With Ion Source Mini Leak Detection Rate 2.5*10-9 Pa.m3/s

Product Description:

As its name suggests, this vacuum leak detector works by detecting helium, a highly sensitive tracer gas that can reveal even the tiniest leaks in vacuum systems. This makes it ideal for a wide range of industrial vacuum detection applications, including but not limited to, semiconductor manufacturing, aerospace, and automotive industries.

The Helium Leak Detector features a fast response time of less than 1s, making it an efficient and reliable tool for detecting and locating vacuum leaks. Its two ion sources, coated with Iridium Coated Yttrium Oxide, automatically switch between modes, enhancing its accuracy and versatility in detecting leaks of different sizes and types.

Communication with the Helium Leak Detector is simple and seamless, thanks to its multiple communication interfaces including RS232/485 and LAN. This allows for easy integration with other systems and devices, and enables data collection and analysis for continuous improvement and optimization of vacuum systems.

In summary, the Helium Leak Detector is a high-quality product that delivers exceptional performance in vacuum detection and leak detection. Its compact design, fast response time, and automatic switching ion sources make it an ideal choice for various industrial vacuum detection applications.

Features:

• Product Name: Helium Leak Detector
• Ion Source: 2pcs, Iridium Coated Yttrium Oxide, Automatic Switching
• Detectable Quality: 2, 3, 4 (H2, He3, He4)
• Mini Leak Detection Rate(Pa.m3/s)/Vaccum Mode: 5*10-13 Pa.m3/s
• Start Time (min): ≤1.58min
• Mini Leak Detection Rate(Pa.m3/s)/Sniffer Mode: 2.5*10-9 Pa.m3/s

This helium leak detection system is equipped with two ion sources, Iridium Coated Yttrium Oxide, and automatic switching. It can detect helium as well as other gases such as H2 and He3. It has a mini leak detection rate of 5*10-13 Pa.m3/s in vacuum mode and 2.5*10-9 Pa.m3/s in sniffer mode. With a start time of ≤1.58 min, this helium leak detection product is a reliable and efficient solution for detecting leaks.

Technical Parameters:

This table shows the technical parameters of a helium leak detector, which is used for helium leak testing and vacuum detection. The table includes information on the leak rate display, language options, mini leak detection rate in vacuum mode, operating temperature, start time, ion source, leak detection port, communication interface, I/O input output interface, and max allowable leak detection pressure.

Applications:

The Wayeal SFJ-231 Helium Leak Detector is a perfect choice for those who need to detect leaks in mass spectrometers. With its high sensitivity and accuracy, this product is able to quickly and easily identify even the smallest leaks, allowing you to troubleshoot and repair your equipment as needed.

In addition to mass spectrometers, the Wayeal SFJ-231 Helium Leak Detector is also a great choice for those who need to detect leaks in other vacuum systems. Whether you're working with vacuum pumps, vacuum chambers, or other industrial vacuum systems, this product will help you quickly and easily identify any leaks, allowing you to keep your equipment running smoothly and efficiently.

If you work in an industrial setting, the Wayeal SFJ-231 Helium Leak Detector is an essential tool for keeping your vacuum systems running smoothly. Use it to detect leaks in industrial vacuum chambers, vacuum pumps, and other vacuum systems. With its high sensitivity and accuracy, this product will help you identify even the smallest leaks, allowing you to make repairs quickly and efficiently.

The Wayeal SFJ-231 Helium Leak Detector has a minimum order quantity of 1 unit, and its price is negotiable. It is packaged in a sturdy wooden case and has a delivery time of 35 days. Payment terms include T/T and VISA, and the product is able to detect leaks in both Chinese and English. Its MES interface is standard, and its mini leak detection rate in vacuum mode is 5*10-13 Pa.m3/s. The start time is ≤1.58min, and the product has a supply ability of 200 units per month.

Customization:

• Brand Name: Wayeal
• Model Number: SFJ-231
• Place of Origin: Anhui, China
• Certification: CE
• Minimum Order Quantity: 1 Unit
• Price: Negotiate
• Packaging Details: Wooden Case
• Delivery Time: 35 days
• Payment Terms: T/T, VISA
• Supply Ability: 200 Units/Month
• MES Interface: Standard
• Communication Interface: RS232/485, LAN
• Leak rate display: Numbers, Bar Charts, Graphs
• Detection Method: Helium Mass Spectrometer
• Leak detection port: DN25KF

Our customization services for this product include:

• Customized specifications to suit your specific needs
• Industrial vacuum detection
• Helium mass spectrometer Leak Detector

Support and Services:

The Helium Leak Detector is a high-precision instrument used to detect and locate gas leaks in a variety of applications, including refrigeration, air conditioning, automotive, aerospace, and more. Our product technical support team is available to assist with any questions you may have regarding the operation and maintenance of the Helium Leak Detector. We also offer a range of services, including calibration, repair, and training, to ensure that your instrument is operating at peak performance. Contact us for more information.
